MIDWEST CHASSIS 82-02 F-BODY HOUSING, TORQUE ARM, CROSSMEMBER, POWERTRAX CENTER SECTION PACKAGE
SPECS:
- CAD Design Components
- Laser Cut
- CNC folds
- DOM Seamless tubing
- Billet Housing Ends
- Fully gusseted design (Internal bulkhead gussets and axle tube go all the way to the carrier studs, fully welded around axle tube, face plate, and housing backside)
- Widest housing design (Increased strength with or without brace. 4-5" of axle tube is welded to the faceplate)
- Rearend assemblies include chromoly adjustable torque arm - tunnel or transmission crossmemeber mount (Torque arm uses aircraft grade, Chromoly, Teflon lined heim joint at the front to allow suspension articulation without binding).
- Transmission crossmember mounted version available for all transmission combos
- Tunnel mount crossmembers are available for cat-back, double drop, turbo, and true duals which also include the driveshaft loop at no charge
- Our torque arm is mounted to the crossmember with a 5-hole height adjustable pivot link
- Street version pivot link is mounted to the crossmember with a Energy Suspension polyurethane bushing to eliminate noise
- All bracketry retains stock mounting locations and geometry
The following features are included at NO additional charge:
- Any available width
- 5 position adjustable relocator style lower control arm brackets
- Drain plug
- Stock style mounted anti-sway bar brackets installed
- Brake hose brackets installed
- 1998-2002 rearend models include e-brake cable bracket installed
- Brake line clips welded on
- Chassis brake hose adapter included
- Housing vent
- Grade 8 hardware included for all brackets - no other manufacturers do this
- ARP housing studs
Base center section includes:
- Strange Nodular Case (rated 600hp)
- Powertrax Preloaded Helical Gear Style Posi(2 Year Manufacturer Warranty)
- Choice Of Gear Ratio
Strange Axle Options:
- Standard 35spl Axles
- 12mm Studs
- 1/2 Studs
- 5/8 Studs
The following features are available for an additional charge:
- Narrowed lower control arm brackets available
- Tapered housing backbrace installation
- Industrial grade powdercoating available
- Wheelie bar mounts
- Transverse shock mounts
- Tow Loops
- Additional Remote Filler Cap
- Call with any other custom needs not listed
Additional options available in our store:
- Driveshaft Safety Loop (Long Arm)
- Lower Control Arms
- Anti Roll Bar
- Watts Link
- Driveshaft
Free Shipping to the lower 48 States on non-assembled packages. Center sections will be assembled and shipped separate from the housing.
Customer must supply brake backing plates or choose the option for Strange/Wilwood Brakes.
NOTE: Third Gen torque arm crossmember requires welding & subframe connectors.
NOTE: Cars retaining factory LT brakes can only be narrowed 1" per side due the the caliper size.
NOTE: True Dual Crossmember must use our two piece torque arm to get full pinion angle adjustment. With higher HP vehicles we suggest upgrading to our double wall version.
NOTE: Wilwood & Strange brake options cannot support 4CH ABS/TCS
P/N HP-F8202-HPP
