MIDWEST CHASSIS 82-02 F-BODY HOUSING, TORQUE ARM, CROSSMEMBER, S-TRAC CENTER SECTION PACKAGE.
SPECS:
- CAD Design Components
- Laser Cut
- CNC folds
- DOM Seamless tubing
- Billet Housing Ends
- Fully gusseted design (Internal bulkhead gussets and axle tube go all the way to the carrier studs, fully welded around axle tube, face plate, and housing backside)
- Widest housing design (Increased strength with or without brace. 4-5" of axle tube is welded to the faceplate)
- Rearend assemblies include chromoly adjustable torque arm - tunnel or transmission crossmemeber mount (Torque arm uses aircraft grade, Chromoly, Teflon lined heim joint at the front to allow suspension articulation without binding).
- Transmission crossmember mounted version available for all transmission combos
- Tunnel mount crossmembers are available for cat-back, double drop, turbo, and true duals which also include the driveshaft loop at no charge
- Our torque arm is mounted to the crossmember with a 5-hole height adjustable pivot link
- Street version pivot link is mounted to the crossmember with a Energy Suspension polyurethane bushing to eliminate noise
- All bracketry retains stock mounting locations and geometry
The following features are included at NO additional charge:
- Any available width
- 5 position adjustable relocator style lower control arm brackets
- Drain plug
- Stock style mounted anti-sway bar brackets installed
- Brake hose brackets installed
- 1998-2002 rearend models include e-brake cable bracket installed
- Brake line clips welded on
- Chassis brake hose adapter included
- Housing vent
- Grade 8 hardware included for all brackets - no other manufacturers do this
- ARP housing studs
Base center section includes:
- Strange Nodular Case (rated 600hp)
- S-Trac
- Choice Of Gear Ratio
Strange Axle Options:
- Standard 35spl Axles
- 12mm Studs
- 1/2 Studs
- 5/8 Studs
The following features are available for an additional charge:
- Narrowed lower control arm brackets available
- Tapered housing backbrace installation
- Industrial grade powdercoating available
- Wheelie bar mounts
- Transverse shock mounts
- Tow Loops
- Additional Remote Filler Cap
- Call with any other custom needs not listed
Additional options available in our store:
- Driveshaft Safety Loop (Long Arm)
- Lower Control Arms
- Anti Roll Bar
- Watts Link
- Driveshaft
- Stainless Brake Hose Kits for Strange Brakes
Free Shipping to the lower 48 States on non assembled packages. Center sections will be assembled and shipped separate from housing.
Customer must supply brake backing plates or choose the option for Strange/Wilwood Brakes.
NOTE; Third Gen torque arm crossmember requires welding & subframe connectors.
NOTE: Cars retaining factory LT brakes can only be narrowed 1" per side due to the size of the caliper.
NOTE: True Dual Crossmember must use our two piece torque arm to get full pinion angle adjustment. With Higher HP vehicles we suggest upgrading to our double wall version.
NOTE: Wilwood & Strange brake options cannot support 4CH ABS/TCS
P/N HP-F8202-HST
