• 82-02 F-Body Fabricated Nine Inch Housing & Torque Arm Package

    $1,299.00
    Free Shipping!

    MIDWEST CHASSIS 82-02 F-BODY HOUSING AND TORQUE ARM PACKAGE.

    SPECS:

    • CAD Design Components
    • Laser Cut
    • CNC folds
    • DOM Seamless tubing
    • Billet Housing Ends
    • Fully gusseted design (Internal bulkhead gussets and axle tube go all the way to the carrier studs, fully welded around axle tube, face plate, and housing backside)
    • Widest housing design (Increased strength with or without brace. 4-5" of axle tube is welded to the faceplate)
    • Rearend assemblies include chromoly adjustable torque arm - tunnel or transmission crossmemeber mount (Torque arm uses aircraft grade, Chromoly, Teflon lined heim joint at the front to allow suspension articulation without binding).
    • Transmission crossmember mounted version available for all transmission combos
    • Tunnel mount crossmembers are available for cat-back, double drop, turbo, and true duals which also include the driveshaft loop at no charge
    • Our torque arm is mounted to the crossmember with a 5-hole height adjustable pivot link
    • Street version pivot link is mounted to the crossmember with a Energy Suspension polyurethane bushing to eliminate noise
    • All bracketry retains stock mounting locations and geometry


    The following features are included at NO additional charge:

    • Any available width
    • 5 position adjustable relocator style lower control arm brackets
    • Drain plug
    • Stock style mounted anti-sway bar brackets installed
    • Brake hose brackets installed
    • 1998-2002 rearend models include e-brake cable bracket installed
    • Brake line clips welded on
    • Chassis brake hose adapter included
    • Housing vent
    • Grade 8 hardware included for all brackets - no other manufacturers do this
    • ARP housing studs


    The following features are available for an additional charge:

    • Narrowed lower control arm brackets available
    • Tapered housing backbrace installation
    • Industrial grade powdercoating available
    • Wheelie bar mounts
    • Transverse shock mounts
    • Tow Loops
    • Additional Remote Filler Cap
    • Call with any other custom needs not listed

    Additional options available in our store:
    • Driveshaft Safety Loop (Long Arm)
    • Lower Control Arms
    • Anti Roll Bar
    • Watts Link

    Free Shipping to the lower 48 States, shipping charges will apply other wise.

    NOTE: Third Gen torque arm crossmember requires welding & subframe connectors.
    NOTE: LT equipped brakes can only be narrowed 1" per side do the caliper size.
    NOTE: True Dual Crossmember must use our two piece torque arm to get full pinion angle adjustment. With Higher HP vehicles use our double wall version.


    HP-F8202-HT

    Please note that shipping costs & free shipping items are for the US continental 48 states only. Currently our website cannot process shipping/duties/taxes for international orders or orders outside of the US continental 48 states. We strongly suggest that these customers email sales@midwestchassis.com for shipping quotes prior to attempting purchase online as all refund transactions will incur an administrative/cancellation fee.

    Built To Order, any questions or customization's please feel free to call. (309)382-6252
