Double Adjustable Rear Coil-Over Shock
1979-2004 Mustang (excluding 99-04 Cobra)

Sold as Each

Features
• Lightweight aluminum body
• 10 extension & compression settings
• Provides a wide range of control
• Easily accessible independent external adjustment knobs
• Allows quick changes for varying conditions
• Rotating knobs clockwise stiffens valving
• Coil-over design simplifies changes to ride height
• Custom valving available upon request
• .5625″ bumper height
• Ability to be rebuilt or revalved
• Accepts 14″ x 2.50″ I.D. spring

Includes
• Upper & lower spring seats
• Lower seat jam nut
• Upper stud with rubber cushions
• Concave washers & lock nut
• Lower spherical ball bearing
• Lower bracket – Drilling required
• Mounting hardware

Dimension A
Without bumper
• 18.71″ extended
• 12.2″ compressed
• 6.51 stroke

Dimension A
With bumper
• 18.71″ extended
• 12.76″ compressed
• 5.95″ stroke

Adjustments For Drag Racing
Softening extension allows more downward force on the rear tires
Stiffening compression delays the return to normal ride height

Adjustments For Performance Street & Road Racing
Stiffening extension & compression reduces body roll
Enhances handling & cornering characteristics

CLICK HERE for install instructions & parts list
